Starmanifold Starwheel injection system
The Starwheel and Starmanifold injection systems designed by Definox allow for personalizable multi-points injection of flavors, colorants and additives into the fluid process, closest to the fluid stream. According to the injection needs, the valves can be put in place or taken out quickly.
The benefits
The product features
DN 2″, 2.5″, 3″ or 4″, for the main Stream
- Injection points: DN 20, 17, 13, 10, 7, 5, 3.
Easy assembly and disassembly
- Injection valves connected to the main pipeline thanks to clamp connections.
Options
- Set of injection quills.
PEEK or PFA plug
Various material for many applications
- EPDM, FKM, FFKM or VMQ seals
- Stainless steel 316L 1.4404
- On request, 254 SMO, AL-6XN, Uranus B6, Hastelloy C22, 904L.
Variants for injection solutions
- From a piggable VEOX mixproof valve, multisize bodied version
- From a compact manifold of 3 valves, connected to the main pipeline.
Precise injection with Starwheel solution
- Interchangeability of the injection valves
- Many injection points
- Circulation loop of injected product from DCX4 fractional divert valve
Starmanifold
- Injection from the main pipeline wall
- Non interchangeable injection points.
Documentary Resources
CAD 3D 2D ePortal
Go to our symbols Library 2D or 3D, available in all CAD formats 2D, 3D, native or neutral. Select and download the symbols from our online configurator.
Related products
Manifold or valve fitting assembly
Designed with care and built to last, the manifolds manufactured by Definox comply with the most stringent demands on sanitary processes.
Taking care to satisfy the ergonomic and safety concerns of industrial companies, Definox integrates, throughout their range of valves, devices that enable easy installation and accessibility to the valves. Issues concerning geometry, size and intended function, including the most complex, are all fully considered during the designing and manufacturing of these assemblies.
VEOX double independent plugs mixproof valve
With no product loss on opening, the VEOX double independent plugs mixproof valve, integrates a physical break between 2 circuits. This technology allows for the visualization of possible leaks and the secure flow of 2 different fluids with no cross contamination. The plug lifting ensures complete cleaning without opening the valve.
DCX3 FRACT fractional shut-off valve
The small size single sealing valves are leakproof under high-pressure. They fit the Starmotion pigging system and the injection system Starwheel.
